Stainless Steel Cold Room Floor Panel
The Stainless Steel Cold Room Floor Panel is a heavy-duty insulated stainless floor system designed for cold storage rooms, deep freezers, food processing plants, meat facilities, seafood areas, logistics warehouses, pharmaceutical cold storage, and industrial cold chain operations. Built for demanding cold environments, this stainless floor panel supports hygienic cleaning, strong load resistance, reliable insulation, and long-term floor durability.
In industrial cold rooms, stainless floor performance directly affects hygiene, safety, energy efficiency, and daily workflow. A weak or poorly insulated floor can cause heat transfer, moisture problems, surface damage, cleaning difficulties, and reduced cold room efficiency. The Stainless Steel Cold Room Floor Panel helps reduce these risks with a durable stainless surface, reinforced floor structure, and high-density polyurethane insulated core.
The stainless floor surface provides strong resistance against corrosion, moisture, cleaning chemicals, pallet movement, carts, and heavy warehouse equipment. This stainless construction makes the stainless floor design suitable for facilities operating under strict food safety standards. In freezer environments down to -40°C (-40°F), the insulated stainless floor structure helps reduce heat transfer while supporting energy-efficient cold storage operation.
Designed for modular cold room panel systems, the Stainless Steel Cold Room Floor Panel provides a reinforced stainless floor surface suitable for personnel traffic, pallet jacks, forklifts, and industrial use. Its strong stainless floor construction helps distribute heavy loads while maintaining insulation continuity across the cold room floor.
For projects where stainless floor hygiene, stainless durability, stainless floor strength, thermal insulation, and long-term reliability must work together, the Stainless Steel Cold Room Floor Panel provides a durable insulated floor solution for professional cold storage facilities.
| Specifications | Technical details |
|---|---|
| Door type | Stainless steel hinged cold room door |
| Application | Cold room / Freezer / Hygienic cold room |
| Surface material | AISI 304 stainless steel (AISI 316 available as an option) |
| Insulation core | High-density polyurethane foam |
| Insulation density | 40–45 kg/m³ |
| Thermal conductivity (λ) | ≤ 0.022 W/m·K |
| Door thickness options | 60 mm (2.36 in) / 80 mm (3.15 in) / 100 mm (3.94 in) / 120 mm (4.72 in) |
| R-value (60 mm) | R-15 (ft²·°F·h/BTU) |
| R-value (80 mm) | R-20 |
| R-value (100 mm) | R-25 |
| R-value (120 mm) | R-30 (high performance standard for cold storage warehouses) |
| U-value (120 mm) | Approximately 0.18 W/m²K |
| Frame construction | Insulated stainless steel or aluminum frame |
| Hinge system | Heavy-duty adjustable stainless steel hinges |
| Sealing system | Magnetic seal with optional heated frame (for freezer use) |
| Operating temperature range | +2°C to -40°C (35.6°F to -40°F) |
| Frost prevention (freezer) | Optional heated threshold and anti-condensation system |
| Air tightness | Industrial multi-point heat sealing |
| Compliance with hygiene standards | Compliant with HACCP standards and food processing standards |
| Customized production | Fully customizable according to project dimensions |
