Flush Mount Cooler Swing Door
Freezewize Flush-Mounted Hinged Cold Room Door is a high-performance insulated industrial door designed for walk-in coolers, walk-in freezers, and temperature-controlled cold storage facilities that require seamless panel integration and high R-value thermal insulation. As a recessed cold room door and hinged refrigeration door system, it is specifically designed for industrial refrigeration environments where hygiene standards, energy efficiency, and structural compatibility are critical. This insulated flush-mounted refrigeration and freezer door solution is widely used in food processing plants, supermarkets, logistics warehouses, pharmaceutical cold storage facilities, and large-scale industrial cold chain facilities seeking reliable insulation and architectural consistency.
The flush-mounted configuration creates a smooth interior surface by directly aligning the door leaf and frame with modular cold room panels, reducing thermal bridges and improving airtightness performance. In refrigeration applications, it supports stable temperature control and energy-efficient operation, while in freezer environments, it can be configured with advanced insulation and heated sealing systems to maintain performance in sub-zero conditions below -40°C (-40°F).
Manufactured with high-density polyurethane insulation and reinforced structural components, the Flush-Hinged Cold Room Door provides long-term durability in heavy industrial use. The heavy-duty adjustable hinge system ensures stable operation, and the precision magnetic sealing system minimizes air leakage. Fully compatible with modular cold room panel systems, the door is designed with region-appropriate refrigerant supply and can be integrated with facilities that comply with international industrial and hygiene standards.
For projects requiring insulation performance, clean structural design, and reliable operation, this recessed hinged door offers a balanced and energy-efficient solution for both refrigeration and freezing applications.
| Specification | Technical details |
|---|---|
| Door type | Flush-mounted cold room door with hinges |
| Application | Walk-in cold room / Walk-in freezer room / Industrial cold room |
| Insulation core | High-density polyurethane foam |
| Insulation density | 40–45 kg/m³ |
| Thermal conductivity (λ) | ≤ 0.022 W/m·K |
| Door thickness options | 60 mm (2.36 inches) / 80 mm (3.15 inches) / 100 mm (3.94 inches) / 120 mm (4.72 inches) |
| R-value (60 mm) | R-15 (ft²·°F·hr/BTU) |
| R-value (80 mm) | R-20 |
| R-value (100 mm) | R-25 |
| R-value (120 mm) | R-30 (high-performance standard for cold storage) |
| U-value (120 mm) | Approx. 0.18 W/m²K |
| Surface options | Pre-painted galvanized steel / AISI 304 stainless steel |
| Frame construction | Flush-mounted, insulated aluminum or stainless steel |
| Hinge system | Heavy-duty, adjustable industrial hinges |
| Sealing system | Magnetic seal with optional heated frame (freezer configuration) |
| Operating temperature range | +2 °C to -40 °C (35.6 °F to -40 °F) |
| Ice prevention (freezer) | Optional heated threshold and anti-condensation system |
| Air tightness | High-performance multi-point thermal seal |
| Customized manufacturing | Fully adaptable to project dimensions |
